Operating instructions – ebm-papst A3G560-AP68-35 User Manual
Page 4
Operating instructions
A3G560-AP68-35
Translation of the original operating instructions
3. TECHNICAL DATA
3.1 Product drawing
All measures have the unit mm.
1
Direction of air flow "A"
2
Cable diameter: min. 4 mm, max. 10 mm; tightening torque: 2.5±0.4 Nm
3
Thread reach max. 16 mm
4
Tightening torque 3.5±0.5 Nm
Item no. 52199-5-9970 · Revision 83139 · Release 2014-07-14 · Page 4 / 12
ebm-papst Mulfingen GmbH & Co. KG · Bachmühle 2 · D-74673 Mulfingen · Phone +49 (0) 7938 81-0 · Fax +49 (0) 7938 81-110 · [email protected] · www.ebmpapst.com
