Operating instructions – ebm-papst A3G400-AN04-03 User Manual
Page 4
Operating instructions
A3G400-AN04-03
Translation of the original operating instructions
3. TECHNICAL DATA
3.1 Product drawing
All measures have the unit mm.
1
Direction of air flow "V"
2
Depth of screw max. 10 mm
3
Connection line PVC 3G AWG20, 3x brass lead tips crimped
4
Connection line PVC 4X AWG22, 4x brass lead tips crimped
Item no. 51543-5-9970 · Revision 75470 · Release 2011-12-13 · Page 4 / 10
ebm-papst Mulfingen GmbH & Co. KG · Bachmühle 2 · D-74673 Mulfingen · Phone +49 (0) 7938 81-0 · Fax +49 (0) 7938 81-110 · [email protected] · www.ebmpapst.com
