Operating instructions
A3G300-AK13-01
Translation of the original operating instructions
3. TECHNICAL DATA
3.1 Product drawing
All measures have the unit mm.
1
Direction of air flow "V"
2
Depth of screw max. 5 mm
3
Connection line PVC 4G 0.5 mm², 4x brass lead tips crimped
