Operating instructions P2E070-AA26-01
Translation of the original operating instructions
3.2 Nominal data
Motor M2E068-BF
Phase 1~ 1~
Nominal voltage / VAC 230 230
Frequency / Hz 50 60
Type of data definition fc fc
Valid for approval /
standard CE CE
Speed / min -1 2250 2300
Power input / W 58 70
Current draw / A 0.26 0.31
Motor capacitor / µF 1.5 1.5
Capacitor voltage / VDB 400 400
Max. ambient
temperature / °C 45 50
Min. temp. of flow
medium / °C 0 0
Max. temp. of flow
medium / °C 40 40
Pump capacity / m 3 /h 0.71 0.74
Max. Pumping head / m 6.1 7.2
ml = max. load · me = max. efficiency · fc = free conveying
cs = customer specs · cu = customer unit
Subject to alterations
3.3 Technical features
Mass 1.6 kg
Size 70 mm
Surface of rotor Coated in black
Material of terminal box Fiberglass-reinforced plastic
Material of impeller Fiberglass-reinforced plastic
Material of agitator
propeller PE
Material of pump
housing Fiberglass-reinforced plastic
Material of cross-
member Fiberglass-reinforced plastic
Direction of rotation Clockwise, seen on rotor
Type of protection IP 44
Insulation class "B"
Humidity class F2-2
Mounting position Vertical
Condensate discharge
holes On the stator side
Operation mode S1
Motor bearing Ball bearing
Touch current acc.
IEC 60990 (measuring
network Fig. 4, TN
system) < 0.75 mA
Electrical leads Via terminal box, integrated capacitor
connected via terminal box
Motor protection Thermal overload protector (TOP) wired
internally
Cable exit Lateral
Protection class I (if protective earth is connected by
customer)
Product conforming
to standard EN 60335-1; CE
For cyclic speed loads, note that the rotating parts of the device
are designed for maximum one million load cycles. If you have
specific questions, contact ebm-papst for support.
3.4 Mounting data
; Secure the mounting screws against accidentally coming loose (e.g.
by using self-locking screws).
Strength class for
mounting screws 8.8
You can obtain additional mounting data from the product drawing if
necessary.
3.5 Transport and storage conditions
; Use the device in accordance with its protection type.
