Operating instructions M3G084-GF08-81
Translation of the original operating instructions
3.2 Nominal data
Motor M3G084-GF
Phase 1~
Nominal voltage / VAC 230
Nominal voltage
range / VAC 200 .. 277
Frequency / Hz 50/60
Type of data definition ml
State prelim.
Speed / min -1 1500
Power input / W 392
Power output / W 314
Current draw / A 1.7
Rated torque / Ncm 200
Min. ambient
temperature / °C -25
Max. ambient
temperature / °C 40
ml = max. load · me = max. efficiency · fa = running at free air
cs = customer specs · cu = customer unit
Subject to alterations
3.3 Technical features
Mass 6.8 kg
Size 84 mm
Material of electronics
housing Die-cast aluminium
Housing material Die-cast aluminium
Direction of rotation Counter-clockwise, seen on shaft
Type of protection IP 55
Insulation class "B"
Humidity class F3-1
Mounting position Any
Cooling bore / aperture Rotor-side
Operation mode S1
Motor bearing Ball bearing
Technical features - Output 10 VDC, max. 10 mA
- Alarm relay
- Motor current limit
- PFC, active
- Soft start
- Control input 0-10 VDC / PWM
- Control interface with SELV potential
safely disconnected from the mains
- Over-temperature protected
electronics / motor
- Line undervoltage / phase failure
detection
Touch current acc.
IEC 60990 (measuring
network Fig. 4, TN
system) <= 3.5 mA
Motor protection Thermal overload protector (TOP) wired
internally
Protection class I (if earth wire is connected by customer)
Product conforming
to standard EN 61800-5-1; CE
For cyclic speed loads, note that the rotating parts of the device
are designed for maximum one million load cycles. If you have
specific questions, contact ebm-papst for support.
3.4 Mounting data
For depth of screw, see chapter 3.1 Product drawing
; Secure the mounting screws against accidentally coming loose (e.g.
by using self-locking screws).
Strength class for
mounting screws 8.8
You can obtain additional mounting data from the product drawing if
necessary.
3.5 Transport and storage conditions
; Use the device in accordance with its protection type.
Max. permissible
ambient motor temp.
(transp./ storage) + 80 °C
Min. permissible
ambient motor temp.
(transp./storage) - 40 °C
3.6 Electromagnetic compatibility
EMC interference
immunity Acc. to EN 61000-6-2 (industrial
environment)
EMC harmonics Acc. to EN 61000-3-2/3
EMC interference
emission Acc. to EN 55022 (Class B)
Item no. 50840-5-9970 · Revision 77360 · Release 2012-12-11 · Page 5 / 10
