Operating instructions M3G084-DF18-81
Translation of the original operating instructions
4.3 Connection of the cables
External leads are brought out of device.
; First connect the "PE" (protective earth) connection.
● Connect the lines according to your application. When doing so,
observe chapter 4.5 Connection screen.
4.4 Factory settings
Factory settings with which the device is pre-set by ebm-papst.
Operation mode PWM controlling
Group adress 01
Fan / device adress 01
Max. PWM / % 100
Min. PWM / % 0
Save set value to
EEPROM No
Set value control Analog
Control function Positive (heating)
