Operating instructions G1G170-AB05-81
Translation of the original operating instructions
You can control the blower either via the 0-10 VDC input or the
PWM input. Note: Inputs cannot be used simultaneously.
3.2 Nominal data
Motor M1G074-CF
Phase 1~
Nominal voltage in VAC 115
Frequency in Hz 50/60
Type of data definition fa
Speed in min -1 5730
Power input in W 345
Current draw in A 4.0
Min. ambient
temperature in °C - 25
Max. ambient
temperature in °C + 55
Min. temp. of flow
medium in °C -25
Max. temp. of flow
medium in °C +80
ml = max. load · me = max. efficiency · fa = running at free air
cs = customer specs · cu = customer unit
Subject to alterations
3.3 Technical description
Mass 4.4 kg
Size 170 mm
Surface of rotor Coated in black
Material of protective
cover Polyflam RPP 374-ND CS1 (UL 97-V0)
Material of impeller Aluminium sheet
Housing material Die-cast aluminium
Direction of rotation Clockwise, seen on rotor
Type of protection IP 20
Insulation class "B"
Humidity class F0
Mounting position Any
Cooling bore / aperture Rotor-side
Operation mode S1
Premix If gas is premixed in the blower, a
special blower must be used. Contact us
for details.
Motor bearing Ball bearing
Technical features - Output 10 VDC, max. 10 mA
- Tach output
- Motor current limit
- Control input 0-10 VDC / PWM
- Over-temperature protected motor
Leakage current <= 3.5 mA
Electrical leads With plug
Motor protection Thermal overload protector (TOP) wired
internally
Approval UL 507; CSA C22.2 Nr.113
For cyclic speed loads, note that the rotating parts of the device
are designed for maximum one million load cycles. If you have
specific questions, contact ebm-papst for support.
3.4 Mounting data
For depth of screw, see chapter 3.1 Graphic rendition of products
; Secure the mounting screws against accidentally coming loose (e.g.
by using self-locking screws).
Strength class for
mounting screws 8.8
You can obtain additional mounting data from the product drawing if
necessary.
3.5 Transport and storage conditions
; Use the device in accordance with its protection type.
Max. permissible
ambient motor temp.
(transp./ storage) +80 °C
Min. permissible
ambient motor temp.
(transp./storage) -40 °C
3.6 Electromagnetic compatibility
EMC interference
immunity Acc. to EN 61000-6-2
EMC interference
emission Acc. to EN 61000-6-3 (household
environment)
