Operating instructions
R3G133-RA01-01
Translation of the original operating instructions
3. TECHNICAL DATA
3.1 Graphic rendition of products
All measures have the unit mm.
1
Connection line PVC 4G AWG20, 4x brass lead tips crimped
2
Accessory part: Inlet nozzle 09566-2-4013, not included in the standard scope of delivery
3
Depth of screw max. 5 mm
