Operating instructions
K3G250-AY11-C4
Translation of the original operating instructions
3. TECHNICAL DATA
3.1 Product drawing
All measures have the unit mm.
1
Cable diameter min. 4 mm, max. 10 mm; tightening torque 2.5±0.4 Nm
2
Inlet nozzle with pressure tap (k-factor: 70)
3
Tightening torque 3.5±0.5 Nm
