Operating instructions R4D200-AL12-05
Translation of the original operating instructions
3.2 Nominal data
Motor M4D074-EI
Phase 1~ 1~ 1~ 1~
Nominal voltage / VAC 230 230 400 400
Connection Δ Δ Y Y
Frequency / Hz 50 60 50 60
Type of data definition fa ml fa ml
Valid for approval /
standard CE CE CE CE
Speed / min -1 1350 1530 1350 1530
Power input / W 285 360 285 360
Current draw / A 1.0 1.13 0.58 0.65
Min. back pressure / Pa 0 200 0 200
Min. ambient temperature
/ °C -25 -25 -25 -25
Max. ambient
temperature
/ °C 45 45 45 45
ml = Max. load · me = Max. efficiency · fa = Running at free air
cs = Customer specs · cu = Customer unit
Subject to alterations
3.3 Data according to ErP directive
Installation category A
Efficiency category Static
Variable speed drive No
Specific ratio * 1.00
* Specific ratio = 1 + p fs / 100 000 Pa
Actual Request
2013 Request
2015
Overall efficiency η es / % 29.5 25.8 32.8
Efficiency grade N 40.7 37 44
Power input P e / kW 0.17
Air flow q v / m³/h 805
Pressure increase total p sf / Pa 234
Speed n / min -1 1425
Data definition with optimum efficiency.
The ErP data is determined using a motor-impeller combination in a standardised
measurement configuration.
3.4 Technical features
Mass 4 kg
Size 200 mm
Surface of rotor Coated in black
Material of impeller Sheet steel, hot-dip galvanised
Direction of rotation Clockwise, seen on rotor
Type of protection IP 44
Insulation class "B"
Humidity class F1-2
Mounting position Any
Condensate discharge
holes Rotor-side
Operation mode S1
Motor bearing Ball bearing
Touch current acc.
IEC 60990 (measuring
network Fig. 4, TN
system) < 0.75 mA
Cable exit Axial
Protection class I (if protective earth is connected by
customer)
Product conforming
to standard EN 60335-1, motor does not have
factory-installed overheating protection
For cyclic speed loads, note that the rotating parts of the device
are designed for maximum one million load cycles. If you have
specific questions, contact ebm-papst for support.
3.5 Mounting data
For depth of screw, see chapter 3.1 Product drawing
; Secure the mounting screws against accidentally coming loose (e.g.
by using self-locking screws).
Strength class for
mounting screws 8.8
You can obtain additional mounting data from the product drawing if
necessary.
3.6 Transport and storage conditions
; Use the device in accordance with its protection type.
Max. permissible
ambient motor temp.
(transp./ storage) + 80 °C
Min. permissible
ambient motor temp.
(transp./storage) - 40 °C
