Operating instructions
R3G140-AW05-12
Translation of the original operating instructions
3. TECHNICAL DATA
3.1 Product drawing
All measures have the unit mm.
1
Connection line, 7x brass lead tips crimped
2
Accessory part: Inlet nozzle 09576-2-4013, not included in the standard scope of delivery
3
Depth of screw max. 6 mm
4
Depth of screw max. 6 mm
