Operating instructions – ebm-papst R2E140-AE77-05 User Manual
Page 4
Operating instructions
R2E140-AE77-05
Translation of the original operating instructions
3. TECHNICAL DATA
3.1 Product drawing
All measures have the unit mm.
1
Connection line PVC 4G0.5mm², 4x brass lead tips crimped
2
Accessory part: Inlet nozzle 09576-2-4013, not included in the standard scope of delivery
3
Depth of screw max. 5 mm
Item no. 11045-5-9970 · Revision 71618 · Release 2010-09-17 · Page 4 / 9
ebm-papst Mulfingen GmbH & Co. KG · Bachmühle 2 · D-74673 Mulfingen · Phone +49 (0) 7938 81-0 · Fax +49 (0) 7938 81-110 · [email protected] · www.ebmpapst.com
