Operating instructions G4D200-CL12-01
Translation of the original operating instructions
3.2 Nominal data
Motor M4D074-EI
Phase 3~ 3~ 3~ 3~
Nominal voltage / VAC 230 230 400 400
Connection Δ Δ Y Y
Frequency / Hz 50 60 50 60
Type of data definition fa ml fa ml
Valid for approval /
standard CE CE CE CE
Speed / min -1 1300 1550 1300 1550
Power input / W 360 340 360 340
Current draw / A 1.14 1.07 0.66 0.62
Min. back pressure / Pa 0 250 0 250
Min. ambient temperature
/ °C -25 -25 -25 -25
Max. ambient
temperature
/ °C 45 30 45 30
Starting current / A 1.7 1.7 1.7 1.7
ml = Max. load · me = Max. efficiency · fa = Running at free air
cs = Customer specs · cu = Customer unit
Subject to alterations
3.3 Data according to ErP directive
Installation category B
Efficiency category Total
Variable speed drive No
Specific ratio * 1.00
* Specific ratio = 1 + p f / 100 000 Pa
Actual Request
2013 Request
2015
Overall efficiency η e / % 37.8 30.8 37.8
Efficiency grade N 49 42 49
Power input P e / kW 0.17
Air flow q v / m³/h 800
Pressure increase total p sf / Pa 287
Speed n / min -1 1425
Data definition with optimum efficiency.
The ErP data is determined using a motor-impeller combination in a standardised
measurement configuration.
3.4 Technical features
Mass 7.4 kg
Size 200 mm
Surface of rotor Coated in black
Material of impeller Sendzimir galvanized sheet steel
Housing material Sendzimir galvanized sheet steel
Direction of rotation Clockwise, seen on rotor
Type of protection IP 44; Depending on installation and
position as per EN 60034-5
Insulation class "B"
Humidity class F1-2
Mounting position Shaft horizontal or rotor on bottom; rotor
on top on request
Condensate discharge
holes Rotor-side
Operation mode S1
Motor bearing Ball bearing
Touch current acc.
IEC 60990 (measuring
network Fig. 4, TN
system) < 0.75 mA
Cable exit Axial
Protection class I (if protective earth is connected by
customer)
Product conforming
to standard EN 60335-1
Approval CCC
For cyclic speed loads, note that the rotating parts of the device
are designed for maximum one million load cycles. If you have
specific questions, contact ebm-papst for support.
3.5 Mounting data
For depth of screw, see chapter 3.1 Product drawing
; Secure the mounting screws against accidentally coming loose (e.g.
by using self-locking screws).
Strength class for
mounting screws 8.8
You can obtain additional mounting data from the product drawing if
necessary.
3.6 Transport and storage conditions
; Use the device in accordance with its protection type.
Max. permissible
ambient motor temp.
(transp./ storage) + 80 °C
Min. permissible
ambient motor temp.
(transp./storage) - 40 °C
