Operating instructions G3G146-FK07-02
Translation of the original operating instructions
3.2 Nominal data
Motor M3G055-DF
Phase 1~
Nominal voltage / VAC 230
Nominal voltage
range / VAC 200 .. 240
Frequency / Hz 50/60
Type of data definition ml
Speed / min -1 2320
Power input / W 166
Current draw / A 1.3
Min. ambient
temperature / °C -25
Max. ambient
temperature / °C +60
ml = max. load · me = max. efficiency · fa = running at free air
cs = customer specs · cu = customer unit
Subject to alterations
3.3 Data according to ErP directive
Installation category A
Efficiency category Static
Variable speed drive Yes
Specific ratio * 1.01
* Specific ratio = 1 + p fs / 100 000 Pa
Actual Request
2013 Request
2015
Overall efficiency η es 47.2 25.1 32.1
Efficiency grade N 59.1 37 44
Power input P ed / kW 0.13
Air flow q v / m³/h 350
Pressure increase total p sf / Pa 569
Speed n / min -1 3065
Data established at point of optimum efficiency
3.4 Technical features
Size 146 mm
Material of impeller Sheet steel, galvanised
Housing material Die-cast aluminium
Direction of rotation Clockwise, seen on rotor
Type of protection IP 54; Depending on installation and
position
Insulation class "B"
Mounting position Any
Condensate discharge
holes None, open rotor
Operation mode S1
Motor bearing Ball bearing
Technical features - Output 10 VDC, max. 1.1 mA
- Tach output
- Motor current limit
- Soft start
- Control input 0-10 VDC / PWM
- Over-temperature protected
electronics / motor
- Line undervoltage detection
Touch current acc.
IEC 60990 (measuring
network Fig. 4, TN
system) <= 3.5 mA
Motor protection Locked-rotor protection
Cable exit Variable
Protection class I (if protective earth is connected by
customer)
Product conforming
to standard EN 60335-1
For cyclic speed loads, note that the rotating parts of the device
are designed for maximum one million load cycles. If you have
specific questions, contact ebm-papst for support.
3.5 Mounting data
For depth of screw, see chapter 3.1 Product drawing
; Secure the mounting screws against accidentally coming loose (e.g.
by using self-locking screws).
Strength class for
mounting screws 8.8
You can obtain additional mounting data from the product drawing if
necessary.
3.6 Transport and storage conditions
; Use the device in accordance with its protection type.
Max. permissible
ambient motor temp.
(transp./ storage) + 80 °C
Min. permissible
ambient motor temp.
(transp./storage) - 40 °C
Item no. 51765-5-9970 · Revision 77287 · Release 2012-04-04 · Page 5 / 10
