3.2 Nominal data
Motor M2E074-EI
Phase 1~ 1~
Nominal voltage / VAC 230 230
Frequency / Hz 50 60
Type of data definition fa ml
Valid for approval /
standard CE CE
Speed / min -1 1950 2150
Power input / W 400 415
Current draw / A 1.75 1.82
Motor capacitor / µF 8 8
Capacitor voltage / VDB 400 400
Capacitor standard P0 (CE) P0 (CE)
Min. back pressure / Pa 0 250
Min. ambient
temperature / °C -25 -25
Max. ambient
temperature / °C 40 30
Starting current / A 2.2 2
ml = max. load · me = max. efficiency · fa = running at free air
cs = customer specs · cu = customer unit
Subject to alterations
3.3 Data according to ErP directive
Installation category A
Efficiency category Static
Variable speed drive No
Specific ratio * 1.01
* Specific ratio = 1 + p fs / 100 000 Pa
Actual Request
2013 Request
2015
Overall efficiency η es 33.5 26.5 33.5
Efficiency grade N 44 37 44
Power input P e / kW 0.22
Air flow q v / m³/h 400
Pressure increase total p sf / Pa 665
Speed n / min -1 2705
Data established at point of optimum efficiency
3.4 Technical features
Mass 5.6 kg
Size 180 mm
Surface of rotor Coated in black
Material of impeller Sheet steel, galvanized
Housing material Die-cast aluminium
Direction of rotation Clockwise, seen on rotor
Type of protection IP 44; Depending on installation and
position as per EN 60034-5
Insulation class "B"
Humidity class F0
Mounting position Any
Condensate discharge
holes Rotor-side
Operation mode S1
Motor bearing Ball bearing
Touch current acc.
IEC 60990 (measuring
network Fig. 4, TN
system) < 0.75 mA
Motor protection Thermal overload protector (TOP) wired
internally
Protection class I (if protective earth is connected by
customer)
Product conforming
to standard EN 60335-1; CE
Approval CCC
For cyclic speed loads, note that the rotating parts of the device
are designed for maximum one million load cycles. If you have
specific questions, contact ebm-papst for support.
3.5 Mounting data
For depth of screw, see chapter 3.1 Product drawing
; Secure the mounting screws against accidentally coming loose (e.g.
by using self-locking screws).
Strength class for
mounting screws 8.8
You can obtain additional mounting data from the product drawing if
necessary.
3.6 Transport and storage conditions
; Use the device in accordance with its protection type.
Max. permissible
ambient motor temp.
(transp./ storage) + 80 °C
Min. permissible
ambient motor temp.
(transp./storage) - 40 °C
