Operating instructions G2E140-AI28-01
Translation of the original operating instructions
3.2 Nominal data
Motor M2E068-DF
Phase 1~ 1~ 1~
Nominal voltage / VAC 230 230 230
Frequency / Hz 50 60 60
Type of data definition fa fa fa
Valid for approval /
standard CE CE UL 2111
Speed / min -1 2400 2350 2350
Power input / W 160 205 220
Current draw / A 0.7 0.9 0.96
Motor capacitor / µF 4 4 4
Capacitor voltage / VDB 400 400 400
Min. back pressure / Pa 0 0 0
Min. ambient
temperature / °C -25 -25 -25
Max. ambient
temperature / °C 70 45 45
ml = max. load · me = max. efficiency · fa = running at free air
cs = customer specs · cu = customer unit
Subject to alterations
3.3 Technical features
Mass 3.52 kg
Size 140 mm
Material of impeller Sheet steel, hot-galvanised
Housing material Die-cast aluminium
Direction of rotation Clockwise, seen on rotor
Type of protection IP 44
Insulation class "B"
Humidity class F0
Mounting position Any
Condensate discharge
holes None
Operation mode S1
Motor bearing Ball bearing
Touch current acc.
IEC 60990 (measuring
network Fig. 4, TN
system) < 0.75 mA
Motor protection Thermal overload protector (TOP) wired
internally
Protection class I (if protective earth is connected by
customer)
Product conforming
to standard EN 60335-1; CE
Approval CCC; GOST
For cyclic speed loads, note that the rotating parts of the device
are designed for maximum one million load cycles. If you have
specific questions, contact ebm-papst for support.
3.4 Mounting data
For depth of screw, see chapter 3.1 Product drawing
; Secure the mounting screws against accidentally coming loose (e.g.
by using self-locking screws).
Strength class for
mounting screws 8.8
You can obtain additional mounting data from the product drawing if
necessary.
3.5 Transport and storage conditions
; Use the device in accordance with its protection type.
Max. permissible
ambient motor temp.
(transp./ storage) + 80 °C
Min. permissible
ambient motor temp.
(transp./storage) - 40 °C
