3. TECHNICAL DATA
3.1 Product drawing
All measures have the unit mm.
1
Connection line PVC 3 x 0.25 mm²; 3 x brass lead tips crimped
2
Earth wire AWG20, 1 x brass lead tip crimped
Item no. 11064-5-9970 · Revision 82552 · Release 2014-05-08 · Page 4 / 9
