Operating instructions D4E225-CC01-02
Translation of the original operating instructions
3.2 Nominal data
Motor M4E074-LA
Phase 1~ 1~
Nominal voltage / VAC 230 230
Frequency / Hz 50 60
Type of data definition ml ml
Valid for approval /
standard CE CE
Speed / min -1 1150 1300
Power input / W 650 625
Current draw / A 2.84 2.75
Motor capacitor / µF 25 16
Capacitor voltage / VDB 400 400
Capacitor standard P2 (CE) P2 (CE)
Min. back pressure / Pa 100 300
Min. ambient
temperature / °C -25 -25
Max. ambient
temperature / °C 30 30
ml = max. load · me = max. efficiency · fa = running at free air
cs = customer specs · cu = customer unit
Subject to alterations
3.3 Data according to ErP directive
Installation category B
Efficiency category Total
Variable speed drive No
Specific ratio * 1.00
* Specific ratio = 1 + p f / 100 000 Pa
Actual Request
2013 Request
2015
Overall efficiency η e 36.5 33.9 40.9
Efficiency grade N 44.6 42 49
Power input P e / kW 0.53
Air flow q v / m³/h 1965
Pressure increase total p sf / Pa 361
Speed n / min -1 1335
Data established at point of optimum efficiency
3.4 Technical features
Mass 12.07 kg
Size 225 mm
Material of impeller Sheet steel, hot-galvanised
Housing material Sheet steel, hot-galvanised
Motor suspension Motor anti-vibration mounted on both sides
Direction of rotation Counter-clockwise, seen on rotor
Type of protection IP 22
Insulation class "B"
Humidity class F2-1
Mounting position Any
Condensate discharge
holes None, open rotor
Operation mode S1
Motor bearing Ball bearing
Touch current acc.
IEC 60990 (measuring
network Fig. 4, TN
system) < 0.75 mA
Motor protection Thermal overload protector (TOP) wired
internally
Protection class I (if protective earth is connected by
customer)
Product conforming
to standard EN 60335-1; CE
Approval CCC; GOST
For cyclic speed loads, note that the rotating parts of the device
are designed for maximum one million load cycles. If you have
specific questions, contact ebm-papst for support.
3.5 Mounting data
For depth of screw, see chapter 3.1 Product drawing
; Secure the mounting screws against accidentally coming loose (e.g.
by using self-locking screws).
Strength class for
mounting screws 8.8
You can obtain additional mounting data from the product drawing if
necessary.
3.6 Transport and storage conditions
; Use the device in accordance with its protection type.
Max. permissible
ambient motor temp.
(transp./ storage) + 80 °C
Min. permissible
ambient motor temp.
(transp./storage) - 40 °C
