Operating instructions D4E146-LV19-14
Translation of the original operating instructions
3.2 Nominal data
Motor M4E068-CF
Phase 1~ 1~
Nominal voltage / VAC 230 230
Frequency / Hz 50 60
Type of data definition fa fa
Valid for approval /
standard CE CE
Speed / min -1 780 710
Power input / W 65 68
Current draw / A 0.29 0.3
Motor capacitor / µF 2 2
Capacitor voltage / VDB 400 400
Capacitor standard P2 (CE) P2 (CE)
Min. back pressure / Pa 0 0
Min. ambient temperature
/ °C -25 -25
Max. ambient
temperature
/ °C 50 40
Starting current / A 0.33 0.33
ml = Max. load · me = Max. efficiency · fa = Running at free air
cs = Customer specs · cu = Customer unit
Subject to alterations
3.3 Technical features
Mass 2.5 kg
Size 146 mm
Surface of rotor Uncoated
Material of terminal box PP plastic
Material of impeller PA plastic
Housing material PP plastic
Motor suspension Motor mounted with anti-vibration on both
sides
Direction of rotation Counter-clockwise, seen on rotor
Type of protection IP 44; Depending on installation and
position
Insulation class "F"
Humidity class F0
Mounting position any
Condensate discharge
holes None
Operation mode S1
Motor bearing Ball bearing
Speed steps 5
Touch current acc.
IEC 60990 (measuring
network Fig. 4, TN
system) < 0.75 mA
Electrical leads Via terminal box, integrated capacitor
connected via terminal box; With plug
Motor protection Thermal overload protector (TOP) wired
internally
Cable exit Axial
Protection class I (if protective earth is connected by
customer)
Product conforming
to standard EN 60335-1; CE
Approval CCC
For cyclic speed loads, note that the rotating parts of the device
are designed for maximum one million load cycles. If you have
specific questions, contact ebm-papst for support.
3.4 Mounting data
For depth of screw, see chapter 3.1 Product drawing
; Secure the mounting screws against accidentally coming loose (e.g.
by using self-locking screws).
Strength class for
mounting screws 8.8
You can obtain additional mounting data from the product drawing if
necessary.
3.5 Transport and storage conditions
; Use the device in accordance with its protection type.
Max. permissible
ambient motor temp.
(transp./ storage) + 80 °C
Min. permissible
ambient motor temp.
(transp./storage) - 40 °C
Item no. 10647-5-9970 · Revision 82891 · Release 2014-04-07 · Page 5 / 9
