3.2 Nominal data
Motor M4D068-LA
Phase 3~ 3~ 3~ 3~
Nominal voltage / VAC 230 230 400 400
Connection Δ Δ Y Y
Frequency / Hz 50 60 50 60
Type of data definition fa fa fa fa
Valid for approval /
standard CE CE CE CE
Speed / min -1 1080 1200 1080 1200
Power input / W 480 500 480 500
Current draw / A 1.54 1.50 0.89 0.87
Min. back pressure / Pa 0 100 0 100
Min. ambient temperature
/ °C -25 -25 -25 -25
Max. ambient
temperature
/ °C 30 35 30 35
ml = Max. load · me = Max. efficiency · fa = Running at free air
cs = Customer specs · cu = Customer unit
Subject to alterations
3.3 Data according to ErP directive
Installation category B
Efficiency category Total
Variable speed drive No
Specific ratio * 1.00
* Specific ratio = 1 + p f / 100 000 Pa
Actual Request
2013 Request
2015
Overall efficiency η e / % 40 31.6 38.6
Efficiency grade N 50.6 42 49
Power input P e / kW 0.21
Air flow q v / m³/h 1205
Pressure increase total p sf / Pa 256
Speed n / min -1 1330
Data definition with optimum efficiency.
The ErP data is determined using a motor-impeller combination in a standardised
measurement configuration.
3.4 Technical features
Mass 11 kg
Size 200 mm
Surface of rotor Coated in black
Material of impeller Sheet steel, hot-galvanised
Housing material Sheet steel, hot-galvanised
Motor suspension Motor anti-vibration mounted on both sides
Direction of rotation Counter-clockwise, seen on rotor
Type of protection IP 54
Insulation class "B"
Humidity class F3-1
Mounting position Any
Condensate discharge
holes None
Operation mode S1
Motor bearing Ball bearing
Touch current acc.
IEC 60990 (measuring
network Fig. 4, TN
system) < 0.75 mA
Protection class I (if protective earth is connected by
customer)
Product conforming
to standard EN 60335-1; CE
Approval CCC
For cyclic speed loads, note that the rotating parts of the device
are designed for maximum one million load cycles. If you have
specific questions, contact ebm-papst for support.
3.5 Mounting data
For depth of screw, see chapter 3.1 Product drawing
; Secure the mounting screws against accidentally coming loose (e.g.
by using self-locking screws).
Strength class for
mounting screws 8.8
You can obtain additional mounting data from the product drawing if
necessary.
3.6 Transport and storage conditions
; Use the device in accordance with its protection type.
Max. permissible
ambient motor temp.
(transp./ storage) + 80 °C
Min. permissible
ambient motor temp.
(transp./storage) - 40 °C
Item no. 11305-5-9970 · ENG · Revision 79663 · Release 2014-10-28 · Page 5 / 9
