Operating instructions K1G200-AD49-04
Translation of the original operating instructions
3.2 Nominal data
Motor M1G074-BF
Nominal voltage / VDC 48
Nominal voltage
range / VDC 36 .. 57
Type of data definition fa
State prelim.
Speed / min -1 3650
Power input / W 120
Current draw / A 3.4
Max. back pressure / Pa 410
Min. ambient temperature
/ °C -25
Max. ambient
temperature
/ °C 60
ml = Max. load · me = Max. efficiency · fa = Running at free air
cs = Customer specs · cu = Customer unit
Subject to alterations
3.3 Data according to ErP directive
Installation category A
Efficiency category Static
Variable speed drive Yes
Specific ratio * 1.00
* Specific ratio = 1 + p fs / 100 000 Pa
Actual Request
2013 Request
2015
Overall efficiency η es / % 47.9 27.5 30.5
Efficiency grade N 67.4 47 50
Power input P e / kW 0.14
Air flow q v / m³/h 620
Pressure increase total p sf / Pa 351
Speed n / min -1 3645
Data definition with optimum efficiency.
The ErP data is determined using a motor-impeller combination in a standardised
measurement configuration.
3.4 Technical features
Mass 1.8 kg
Size 200 mm
Surface of rotor Coated in black
Material of impeller Plastic PA6, fibreglass-reinforced
Housing material Plastic PA6, fibreglass-reinforced
Material of support
bracket Plastic PA6, fibreglass-reinforced
Number of blades 7
Direction of air flow "V"
Direction of rotation Clockwise, seen on rotor
Type of protection IP 44; Depending on installation and
position
Insulation class "B"
Humidity class F4-1
Mounting position Any
Condensate discharge
holes None
Operation mode S1
Motor bearing Ball bearing
Technical features - Tach output
- Motor current limit
- Soft start
- Control input 0-10 VDC / PWM
Motor protection Reverse polarity and locked-rotor
protection
Cable exit Lateral
Product conforming
to standard EN 60950-1
Approval CSA C22.2 Nr.77; UL 1004-1
For cyclic speed loads, note that the rotating parts of the device
are designed for maximum one million load cycles. If you have
specific questions, contact ebm-papst for support.
3.5 Mounting data
For depth of screw, see chapter 3.1 Product drawing
; Secure the mounting screws against accidentally coming loose (e.g.
by using self-locking screws).
Strength class for
mounting screws 8.8
You can obtain additional mounting data from the product drawing if
necessary.
3.6 Transport and storage conditions
; Use the device in accordance with its protection type.
Max. permissible
ambient motor temp.
(transp./ storage) + 80 °C
Min. permissible
ambient motor temp.
(transp./storage) - 40 °C
3.7 Electromagnetic compatibility
EMC interference
immunity Acc. to EN 61000-6-2 (industrial
environment)
EMC interference
emission Acc. to EN 55022 (Class B)
