Operating instructions – ebm-papst W1G200-HH01-52 User Manual
Page 4
Operating instructions
W1G200-HH01-52
Translation of the original operating instructions
3. TECHNICAL DATA
3.1 Product drawing
All measures have the unit mm.
1
Connection: terminal strip with 5 terminals.
1.1
UN +48 VDC (red)
1.2
GND (blue)
1.3
DUE (white)
1.4
0-10 VDC (yellow)
2
Direction of air flow "V"
Item no. 50290-5-9970 · ENG · Revision 83494 · Release 2014-09-26 · Page 4 / 9
ebm-papst Mulfingen GmbH & Co. KG · Bachmühle 2 · D-74673 Mulfingen · Phone +49 (0) 7938 81-0 · Fax +49 (0) 7938 81-110 · [email protected] · www.ebmpapst.com
