Operating instructions
W1G130-AA49-01
Translation of the original operating instructions
3. TECHNICAL DATA
3.1 Product drawing
All measures have the unit mm.
1
Direction of air flow "V"
2
Connection line AWG20, 3 x brass lead tips crimped
3
Preferably use 2x Remform screws WN-156-2 5.0x16 Torx galvanised (Arnold). Alternatively use 2x metric M4 screw, mounting
provided with nut
Item no. 51832-5-9970 · ENG · Revision 83269 · Release 2014-07-23 · Page 4 / 10
