13. STEREO (ST) MODE OPERATIONS AND MENUS
13.1. Stereo Mode Home Screen (Playlist)
If the LP-16 has been switched to stereo mode, the ST mode home screen will be displayed.
The ST mode home screen displays pertinent settings and displays, when performing a stereo
playback operation.
1 2 3 4
5
6
7 8
9
1. Mode Status
This icon will display “ST” to show that the LP-16 is currently operating in Stereo mode.
2. Playback Status
This icon shows the current state of the playback transport (play/stop/pause)
3. Playback Mode Icon
This icon shows the specific song-to-song mode that the LP-16 is set to while in stereo mode
(playlist, normal, continuous, repeat, or shuffle).
4. Remaining Time In Song
This counter shows the remaining time left in the currently playing song
5. Playlist Name
This field shows the name of the currently selected playlist
6. Current Song Name
This field shows the name of the song in the playlist that is currently playing back
7. Next Song Icon
This icon indicates how the next song will play back relative to the currently playing song:
•
There will be no pause between the current and the next song
• The next song will pause until play / footswitch is pressed
• The next song will play after seconds specified in playlist. Can be overruled by play
button / footswitch
8. Next Song Name
This field shows the name of the next song in the playlist that will play back when the current one
is completed.
9. Level Meters (-30dB / -3dB / 0dB)
These meters show the output level of the currently playing song. In ST mode, only the 2 output
channels that have been assigned the stereo playback will illuminate with meter activity.
13.2. Stereo Mode Menus
Pressing the Menu Button while in stereo mode will take you to the Stereo Mode Menu.
This menu contains assorted settings that affect the operation of the LP-16 when it is operating
in stereo mode, including the following:
• Playback Mode
• Select playlist (see previous section for details)
• Play-out channels
• Foot switch Settings (see previous section for details)
• Display Settings (see previous section for details)
• Format USB Device (see previous section for details)
Use the Next / Previous buttons, or alternatively the Up / Down buttons, to navigate to the desired
menu setting, which will be highlighted on the display.
Press the Select button to adjust the highlighted selection, and the display will switch to the
specific settings for that menu selection, as detailed below:
13.2.1. Playback Mode
This menu allows you to set the LP-16’s stereo mode to use one of 4 specific playback modes,
which operates as follows:
• Playlist: Files will be played back as part of the playlist they belong to, as configured in the
Playlist Editor software
• Normal: Files will be played back in alphabetical order from the music folder they reside in
• Continuous Play: All of the songs contained in the “Music” folder will be played in
alphabetical sequence
• Repeat: The currently selected song will be repeated endlessly
• Shuffle: The LP-16 will continuously choose songs to play at random.
The currently selected playback mode will be shown, as an icon, at the top of the home page, to
the left of the time counter.
