REFERENCE MEASUREMENTS

Gain change is referenced to having the color function off, it shows some compression
with both the even and odd harmonic controls. Harmonic control at maximum.

All distortion wave measurements use a very low distortion sine wave as the source
They are analog measurements.

SIGNAL

HARM 2

HARM 3

SPEED

HARM 2

HARM 3

LEVEL

= 0

= 1

GAIN

+24 DBU

17.3%

19.7%

15.5%

21.9%

-0.7DB

+14DBU

7.6%

3.5%

16%

14.2%

0.9DB

2.9DB

+4DBU

2.8%

0.6%

1.3%

.05%

1.3DB

3.6DB

-6DBU

0.9%

0.2%

.04%

.03%

1.3DB

3.6DB
