Crane Song STC-8 User Manual
Page 16
Channel 1 PIN#
Channel 2 PIN#
To enable connect PIN 4 to PIN 3
limiter preset enable PIN 12 to PIN 13
SIDE CHAIN CONNECTIONS/PIN OUT CHART
Output: SIG+
10
1
(send)
SIG -
11
9
GND
14
2
Input: SIG +
5
8
(return)
SIG -
6
7
GND
13
15
Unbalanced
Are made by tying the SIG- Pin to the GND Pin. If the connection is an
Connections:
input, it is best to tie at the signal source. If the connection is an output, it
is best to tie at the STC-8 connector.
Power:
100, 120, 230,240 volt; 50/60 Hz; 55 watts
MDL .6A Fuse for 100V and 120V
MDL .3A Fuse for 230V and 240V
Pilot Lamp:
# 7335
Shipping
Weight:
19 lbs. (8.6 kg)
Depth
Behind Panel:
12.5 inches (31.75 cm) plus cabling
Panel Height:
2 rack spaces
PAGE 14
INTERFACING
Input:
Floating, balanced. Maximum input is +25 dBm.
The connectors are XLR.
Output:
Floating, balanced. Maximum output is +25 dBm.
The connectors are XLR.
For Input and Output : Pin 2 is Sig + , Pin 3 is Sig- , Pin 1 is GND
Side Chain
Floating, balanced. Connections are made by using a DB-15
Connections:
Male Connector. This is a loop insert and must be normaled back
to the STC-8.
