Egret db-25 expander connector pin out – Crane Song EGRET User Manual
Page 12
RIGHT 1 RETURN -
1
RIGHT 1 RETURN +
2
LEFT 1 RETURN -
3
LEFT 1 RETURN +
4
RIGHT 2 RETURN -
5
RIGHT 2 RETURN +
6
LEFT 2 RETURN -
7
LEFT 2 RETURN +
8
GND
9
LEFT SEND + (MAIN OUT) 10
LEFT SEND - (MAIN OUT) 11
RIGHT SEND + (MAIN OUT) 12
RIGHT SEND - (MAIN OUT) 13
AUX RETURN 1 SIG -
14
AUX RETURN 1 SIG +
15
AUX RETURN 2 SIG -
16
AUX RETURN 2 SIG +
17
GND
18
SOLO BUS LOGIC
19
SOLO BUS LOGIC
20
GND
21
GND
22
GND
23
AUX SEND +
24
AUX SEND -
25
EGRET DB-25 EXPANDER CONNECTOR PIN OUT
