Cavity Cartridge Fuse Mini-Fuse Description
21 30 Amp Pink Headlamp Washers
28 25 Amp Neutral Fuel Pump
29 15 Amp Blue Transmission Shifter
31 25 Amp Neutral Engine Module
34 25 Amp Neutral Powertrain #1
35 20 Amp Yellow Powertrain #2
36 10 Amp Red Anti-Lock Brake Module
37 10 Amp Red Engine Controller/Rad Fan Relays
38 10 Amp Red Airbag Module
39 10 Amp Red Power Steering Module/AC Clutch Relay
48 10 Amp Red AWD Module/Front Axle Disconnect
51 20 Amp Yellow Vacuum Pump
Rear Power Distribution Center
• There is also a power distribution center located in the trunk under the spare tire access panel.
This center contains fuses and relays.
Cavity Cartridge Fuse Mini-Fuse Description
2 60 Amp Yellow Front PDC Feed #1
4 60 Amp Yellow Front PDC Feed #2
5 30 Amp Pink Sunroof
6 40 Amp Green Exterior Lighting #1
7 40 Amp Green Exterior Lighting #2
8 30 Amp Pink Interior Lighting/Washer Pump
9 30 Amp Pink Power Locks
10 30 Amp Pink Driver Door
11 30 Amp Pink Passenger Door
12 20 Amp Yellow Cigar Lighters, Instrument Panel & Power Outlet
Console Rear
15 40 Amp Green HVAC Blower
23 10 Amp Red Fuel Door/Diagnostic Port
24 15 Amp Blue Radio Screen
25 10 Amp Red Tire Pressure Monitor
27 25 Amp Neutral Amplifier
31 25 Amp Neutral Power Seats
32 15 Amp Blue HVAC Module/Cluster
33 15 Amp Blue Ignition Switch/Wireless Module
34 10 Amp Red Steering Column Module/Clock
35 10 Amp Red Battery Sensor
M A I N T A I N I N G Y O U R V E H I C L E
111
