LIGHT BULBS – Exterior Bulb No.
Bi-Halogen Headlamp . . . . . . . . . . . . . . . . . . . . HIR2
Front Turn Signal Lamp. . . . . . . . . . . . . . . . 3157NAK
Front Park Lamp . . . . . . . . . . . . . . . . . . . . . . . . LED
(Serviced at Authorized Dealer)
Front Fog Lamp . . . . . . . . . . . . . . . . . . . . . . . . . H11
Center High Mounted Stop (CHMSL) Lamp . . . . . LED
(Serviced at Authorized Dealer)
Rear Tail/Stop/Turn Lamp . . . . . . . . . . . . . . . . . LED
(Serviced at Authorized Dealer)
Backup Lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . 921
License Lamp. . . . . . . . . . . . . . . . . . . . . . . . . . W5W
BULB REPLACEMENT
Headlamp
1. Raise and prop open the hood. Locate the connector
behind the headlamp.
NOTE: It may be necessary to remove the air cleaner
filter housing and position the totally integrated power
module aside prior to replacing the low beam headlamp
on the driver’s side of the vehicle.
2. Reach into engine compartment and from behind the
lamp assembly and grasp the connector.
460 MAINTAINING YOUR VEHICLE
