Power outlets – Chrysler 2011 Country - User Guide User Manual
Page 56
POWER OUTLETS
• There are four 12 Volt power outlets in your
vehicle.
• Two are located on the lower instrument
panel, next to the open storage bin. The
upper power outlet is controlled by the
ignition switch and the lower power outlet is
connected directly to the battery.
• One is located in the removable floor
console and is also connected directly to the
battery.
• One is located in the rear quarter panel near the liftgate. This outlet is also controlled by the
ignition switch.
NOTE:
• Do not exceed the maximum power of 160 Watts (13 Amps) at 12 Volts. If the 160 Watt
(13 Amp) power rating is exceeded, the fuse protecting the system will need to be replaced.
• All accessories connected to the “battery” powered outlets should be removed or turned off when
the vehicle is not in use to protect the battery against discharge.
ELECTRONICS
54
