Cavity Cartridge Fuse Mini Fuse Description
17 10 Amp Red
Ignition Off Draw (IOD) — Wireless
Control Module (WCM)/Clock/Steering
Control Module (SCM)
18 40 Amp Green
Battery Feed — Auto Shutdown (ASD)
Relay
19 20 Amp Yellow
Ignition Off Draw (IOD) — Power Amp
Feed 2 - if equipped
20 15 Amp Lt. Blue Ignition Off Draw (IOD) — Radio
21 10 Amp Red Siren — If Equipped
22 10 Amp Red
Ignition Run — Climate Controls/Hot
Cupholder - if equipped
23 15 Amp Lt. Blue Auto Shutdown (ASD) Relay Feed 3
24 25 Amp Natural Battery Feed — PWR Sunroof Feed
25 10 Amp Red
Ignition Run — Heated Mirrors - If
Equipped
26 15 Amp Lt. Blue Auto Shutdown (ASD) Relay Feed 2
27 10 Amp Red
Ignition Run — Occupant Classification
Module (OCM)/Occupant Restraint
Controller (ORC)
28 10 Amp Red
Ignition Run — Occupant Classification
Module (OCM)/Occupant Restraint
Controller (ORC)
29 — — Hot Car (No Fuse Required)
30 20 Amp Yellow
Ignition Run — Heated Seats - If
Equipped
31 10 Amp Red Headlamp Washer — If Equipped
32 30 Amp Pink Auto Shutdown (ASD) Relay Feed 1
33 10 Amp Red
Battery Feed — Switch Bank/Diagnostic
Link Connector/Powertrain Control
Module (PCM)
34 30 Amp Pink
Battery Feed — Anti-Lock Brakes (ABS)
Module - if equipped/Electronic Stability
(ESC) Module - If Equipped
35 40 Amp Green
Battery Feed — Anti-Lock Brakes (ABS)
Module - If Equipped/Electronic
Stability (ESC) Module - If Equipped
36 30 Amp Pink
Battery Feed — Passenger Door Module
(PDM)/Driver Door Module (DDM)
37 25 Amp Natural Power Top Module (If Equipped)
