Cavity

Cartridge

Fuse

Mini

Fuse

Description

32

30 Amp

Pink

—

Auto Shutdown
(ASD) Relay 1

33

—

10 Amp

Red

Switch Bank/
Diagnostic Link
Connector/
Powertrain Control
Module (PCM)

34

30 Amp

Pink

—

Anti-Lock Brakes
(ABS) Module – If
Equipped/Electronic
Stability Control
(ESC) Module – If
Equipped

Cavity

Cartridge

Fuse

Mini

Fuse

Description

35

40 Amp

Green

—

Anti-Lock Brakes
(ABS) Module – If
Equipped/Electronic
Stability Control
(ESC) Module – If
Equipped

36

30 Amp

Pink

—

Passenger Door Mod-
ule (PDM)/Driver
Door Module (DDM)

37

—

25 Amp

Natural

Power Top Module –
If Equipped

432

MAINTAINING YOUR VEHICLE
