Driver Seat Adjustment
SiX-WAy POWeR SeAT SWiTCH
• The seat switch is located on the outboard side of the seat near
the floor. Use this switch to move the seat up or down, forward or
rearward, or tilt the seat.
ReCLineR
• Lean forward before lifting the lever, located on the outboard
side of the seat, then lean back to the desired position and release
the lever.
LUMBAR ADjUSTMenT
• The lumbar adjustment is located on the inboard side of the driver’s
seat. To increase the support, rotate the lever down.
fORWARD/ReARWARD (MAnUAL SeAT)
• Lift up on the adjusting bar, located at the front of the seat near the
floor, and release at the desired position. Refer to Owner’s Manual
for further details.
Tumbling Rear Seat/Seat Removal
• The rear seats can be removed to
increase storage capacity.
• Push and hold the folding rear seat
button to fold the rear seatback down
(toward the front of the vehicle).
• Pull the release strap located on the
outboard side of the seat. Lift up the
seat and tumble the seat forward.
• Attach the tether, located at the base of the
seat cushion, onto the hook bar on the center
trim panel to hold the seat in place.
• To remove seat, lift up on the release levers
located at the base of the rear seat.
• Using the handles located at the top of the tumbled seat, lift and
remove seat through the rear of the vehicle.
• Refer to Owner’s Manual for further details.
Rear
Seat
Button
Power Seat
Switch
Recliner
Lever
Release
Strap
Handle
Release
Levers
