INTEGRATED POWER MODULE (IPM)
Cavity
Cartridge
Fuse
Mini Fuse Description
6 10 Amp Red
IOD Sw/
Pwr Mir/
Ocm Steer-
ing Cntrl
Sdar/Hfm
7
30 Amp
Green
IOD Sense1
8
30 Amp
Green
IOD Sense2
9
40 Amp
Green
Power Seats
10
20 Amp Yel-
low
CCN,
Power
Locks
11
15 Amp Lt
Blue Power Out-
let
INTEGRATED POWER MODULE (IPM)
Cavity
Cartridge
Fuse
Mini Fuse Description
12
20 Amp Yel-
low Ign Run/
Acc Inverter
13
20 Amp Yel-
low
Pwr run/
Acc Outlet
RR
14 10 Amp Red
IOD CCN/
Interior
Lighting
15 50 Amp Red
RAD Fan
Relay Bat-
tery Feed
16
15 Amp Lt.
Blue
IGN Run/
Acc Cigar
Ltr/Sunroof
420 MAINTAINING YOUR VEHICLE
