Cavity Car-
tridge
Fuse Mini
Fuse Description
19 50 Amp
Red — Radiator Fan
20 20 Amp
Blue — Starter
21 50 Amp
Red — Anti-lock Brakes System
(ABS) Pump Motor - if
equipped
22 40 Amp
Green — AC Clutch/Radiator Fan
High — Low
23 50 Amp
Red — High Intensity Lighting
(HID) - if equipped
24 60 Amp
Yellow — Radiator Fan - AWD
25 30 Amp
Pink — Front Control Module
(FCM)
26 20 Amp
Blue — Transmission - RLE
27 30 Amp
Pink — Front Control Module
(FCM)
CAUTION!
• When installing the Power Distribution Center
cover, it is important to ensure the cover is prop-
erly positioned and fully latched. Failure to do so
may allow water to get into the Power Distribu-
tion Center, and possibly result in an electrical
system failure.
• When replacing a blown fuse, it is important to
use only a fuse having the correct amperage
rating. The use of a fuse with a rating other than
indicated may result in a dangerous electrical
system overload. If a properly rated fuse contin-
ues to blow, it indicates a problem in the circuit
that must be corrected.
MAINTAINING YOUR VEHICLE 365
7
