The identity of each fuse is indicated on the backside of
the cover.
Cavity
Fuse
Circuit
1
30 Amp
Green
Blower Motor
2
10 Amp
Red
Right High Beam Headlight,
High Beam Indicator
3
10 Amp
Red
Left High Beam Headlight
4
15 Amp
Blue
Power Door Lock Switch Illu-
mination, Transmission Range
Switch, Daytime Running
Light Module (Canada), Power
Windows, Anti-lock Brake Sys-
tem Module
5
10 Amp
Red
Power Door Lock and Door
Lock Arm/Disarm Switches,
Vanity, Reading, Map, Rear
Seating, Ignition, and Trunk
Lights, Illuminated Entry, Ra-
dio, Power Antenna, Data
Link Connector, Body Control
Module, Power Amplifier
Cavity
Fuse
Circuit
6
10 Amp
Red
Heated Rear Window Indica-
tor
7
20 Amp
Yellow
Instrument cluster illumina-
tion, Park and tail Lights
8
20 Amp
Yellow
Power Receptacle, Horns, Igni-
tion, Fuel, Start
9
15 Amp
Blue
Power Door Lock Motors
(Body Control Module)
10
20 Amp
Yellow
Daytime Running Light Mod-
ule (Canada)
11
10 Amp
Red
Instrument Cluster, Transmis-
sion Control, Park/Neutral
Switch, Body Control Module
12
10 Amp
Red
Left Low beam Headlight
13
20 Amp
Yellow
Right Low Beam Headlight,
Fog Light Switch
14
10 Amp
Red
Radio
