6
Installation
Before proceeding with installation, please read this manual in its entirety.
Step A: Replacing your existing power supply
If you are building a new system, skip to Step B.
1. Disconnect the AC power cord from your wall outlet or UPS and from the existing
power supply.
2. Disconnect all the power cables from your video card, motherboard and all other peripherals.
3. Follow the direction in your chassis manual and uninstall your existing power supply.
4. Proceed to Step B.
Step B
1. Make sure the power supply’s AC power cable is not connected.
2. Follow the directions in your chassis manual and install the power supply with the
screws provided.
3. The main 24-pin power cable attached to the power supply has a detachable 4-pin
mechanism in order to support either a 24-pin or a 20-pin socket on the motherboard.
a. If your motherboard has a 24-pin socket, you may connect the 24-pin main power cable
from the TX Series directly to your motherboard.
b. If your motherboard has a 20-pin socket, you must detach the 4-pin cable from the
24-pin connector, and then plug the 20-pin cable onto your motherboard without
connecting the 4-pin connector.
4. The TX Series has an 8-pin +12V; also know as “EPS12V” cable.
a. If your motherboard has an eight-pin +12V socket, connect the eight-pin cable directly
to your motherboard.
b. If your motherboard has a four-pin socket, detach the four-pin from the eight-pin cable,
and then plug the correct 4-pin directly to your motherboard.
WARNING: The detachable 4-pin from the 24-pin main connector is not a “P4” or “+12V”
connector. Serious damage can be caused if you use it in place of a “P4” or “+12V” connector.
5. The TX Series includes two peripheral cables, four PCI-Express cables (two on the TX650W),
and two SATA cables.
a. Connect the peripherals cables to your hard drive and CD-ROM/DVD-ROM
power sockets.
b. Connect the SATA cables to your SATA hard drive’s power sockets.
c. Connect the PCI-Express cables to the power sockets of your PCI-Express video cards
if required
d. Connect the peripheral cables to any peripherals requiring a small 4-pin connector.
e. Make sure all the cables are tightly connected.
6. Connect the AC power cord to the TX Series and turn it on by pushing the switch to
the “I” position.
Congratulations! You have completed installation of your new TX Series power supply and your
system is ready to go!
Package Contents
• Corsair TX650W/TX750W/TX850W/TX950W Power Supply unit
• User Manual
• AC Power cord
• Cable ties
• Mounting screws
• Corsair case badge
Corsair Cable Configuration
• ATX Power cable: 1 x 610mm (24”) 24-pin.
Note: The ATX power connector has a detachable 4-pin mechanism in order to support
either a 24-pin or a 20-pin socket on the motherboard.
• EPS12V CPU cable: 1 x 610mm (24”) 8-pin.
Note: The EPS12V power connector has a detachable 4-pin mechanism in order to
support either an 8-pin socket or a 4-pin “P4/12V” socket on the motherboard.
• Floppy cable:
TX650/750/850W: 2 x 102mm (4”) 4-pin (attached to the end of Peripheral cable)
TX950W: 2 x 102mm (4”) 4-pin adapter cable.
5
Model
AC Input Rating
Input Current
Frequency
DC Output
+3.3V
+5V
+12V
-12V
+5VSB
Total Power
CMPSU-650TX
90-264VAC
5~12A
47Hz~63Hz
Maximum
Load
24A
30A
52A
0.8A
3A
Maximum
Output
624W
9.6W
15W
650W
170W
CMPSU-750TX
90-264VAC
5~12A
47Hz~63Hz
Maximum
Load
30A
28A
60A
0.8A
3A
Maximum
Output
720W
9.6W
15W
750W
180W
CMPSU-850TX
90-264VAC
5~12A
47Hz~63Hz
Maximum
Load
30A
30A
70A
0.8A
3A
Maximum
Output
840W
9.6W
15W
850W
180W
CMPSU-950TX
90-264VAC
5~12A
47Hz~63Hz
Maximum
Load
25A
25A
78A
0.8A
3A
Maximum
Output
936W
9.6W
15W
950W
150W
QTY
CMPSU-650TX
LENGTH
CONNECTOR
PER CABLE
PCI-E CABLE
2 610mm 1
SATA CABLE
2 864mm 4
PERIPHERAL CABLE
2 1016mm 5
QTY
CMPSU-750TX
LENGTH
CONNECTOR
PER CABLE
PCI-E CABLE
4 610mm 1
SATA CABLE
2 864mm 4
PERIPHERAL CABLE
2 1016mm 5
QTY
CMPSU-850TX
LENGTH
CONNECTOR
PER CABLE
PCI-E CABLE
4 610mm 1
SATA CABLE
2 864mm 4
PERIPHERAL CABLE
2 1016mm 5
QTY
CMPSU-950TX
LENGTH
CONNECTOR
PER CABLE
PCI-E CABLE
6 610mm 1
SATA CABLE
3 864mm 4
PERIPHERAL CABLE
2 864mm 4
