HEADSHOK
1
⅛ “
KP058/ HD169/
QSISEAL/
(adapters w/
headset)
Integrated Head Tube
in both alloy and carbon frame models, the si bearing cups are intergrated within the head
tube. in alloy frames, the cups are machined in the head tube. in carbon models, cups are
permanently bonded into the head tube. Cannondale Headshok system integration bearings
are accepted directly into both type.
an adapter cup kit (KP058/) for 1
⅛” steering tubes and headsets is available (above right) for
either frame type.
CAUTION
1. Do not face, surface, or cut the head tube bearing cups.
2. Please note that when removing bearings from bonded cups, extra care must be used so
that the tool used to drive out the bearing is not located on any part of the bonded cup.
