KENWOOD

2-

din

Listen to the Future

CAW-1200-01

Installation manual for:

Mitsubishi Lancer/ Evo 2004 -->

Installation kit includes the following items:

* 1X 2-ISO 100 mm. metal bracket
* 1X Radio trim
* 1X Replacement panel
* 2X Mounting plates
* 2X Mounting spacers
* 4X Screws
* 2X Radio keys
* 2X Cushion

Kenwood DDX6029

We advice to use the following positions.
Other positions are also possible.

Use position 2 marked with a cross.
Use position 6 & 8 marked with an arrow.
Measured fTom lei^ to right.

Kenwood DDX 7025

We advice to use the following positions.
Other positions are also possible.

Use position 1 marked with a cross.
Use position 14 & 16 marked with an arrow
Measured from lei^ to right.

* Mount the plates.
