MC 800 Indicator Unit-Display
Auio Range 'Zoom''
© © ®
Aim S Aim D
® ®
® © ®
§wiep~Flesh
d
DM'
® @ ©
Reset Light Power
@ © ©
uniden
D1. Surface Water Temperature
D2. Gain Bar Graph
D3. Shallow Alarm Bar Graph
D4. Zoom Cursor
D5. Deep Alarm Bar Graph
D6. Fish Alarm Indicator
D7. Sweep Speed Bar Graph
D8. Zoom On or Auto On Indicator
D9, Current Depth Readout
DIO. Degital Scale
D11.Surface Line
