SPECIFICATIONS
Channels:
40 AM
Freguency Range;
26.965 to 27.405 MHz
Frequency Control:
Phase Locked Loop (PLL) synthesizer
Frequency Tolerance;
+/-0.005%
Operating Temp.:
-30"C to +50°C
Microphone:
Built-in type: electric
Input Voltage:
12.0 VDC nom. (-ground)
Current Drain:
TX: full mod., 1.4A
Size;
RX: with max audio output, 0.5A
2 ^ / g “ W x V / 2 ~ D
X 572”H
Complete Package:
2 lb. 8 oz.
Antenna Connector:
RCA Pin Jack
TRANSMITTER
Power Output:
Selectable HI or LOW
Modulation:
Class B amplitude modulation
Freq. Response;
300 - 3000 Hz
Output Impedance:
50 ohms, unbalanced
RECEIVER
Sensitivity:
0.7fiV
for 1 OdB; (S + N)/N typical
Selectivity:
6dB
(a
7KHz, 70dB
(a
1
OKHz typical
Image Rejection;
75dB typical
I.F Frequency;
Double Conversion Superheterodyne
Automatic Gain Controi
Squelch:
Audio Output Power;
Freq. Response:
Distortion:
Internal Speaker:
1st 10.695 MHz
2nd 455 KHz
(AGC): less than lOdB change in audio output for inputs
from 10 to 50,000 microvolts
Adjustable; threshold less than 1 |
jl
V
0.5 watts max. into 8 ohms
300 to 2500 Hz
less than 10% at 0.4 watts, lOOOHz
16 ohms, 0.4 watts round
SERVICING YOUR CB
Technical information, diagrams and charts
will be provided upon request. It is the
user's responsibility to see that this radio is
operating at all times in accordance with
the D.O.C Citizens Band Radio Service
regulations. We highly recommend that
you consult a gualified radiotelephone
technician for service and alignment of this
radio. When ordering parts, it is important
to specify the correct model number and
serial number of this radio.
Please refer to the WARNING information
on the first page of this manual.
