Specifications
For other Countries
FM tuner Section
Tuning frequency range ............... 87.5 MHz-108 MHz
Usable sensitivity (MONO)................. 0.95 ^xУ/^0.Q dBf
50 dB quieting sensitivity
MONO ........... ..................... .... ........... 1.8 /xV/16.2 dBf
STEREO ..... ........ ................................ 24 ;xV/38.8 dBf
Total harmonic distortion (at 1 kHz)
MONO .
STEREO. .0.04% (WIDE)
.0.06% (WIDE)
Signal to noise ratio (at 1 kHz, 85 dBf input)
MONO ................... ....... ........................................88 dB
STEREO ..... .............................. ..................... ...... 82 dB
Stereo separation
1 kHz ____ __________ __ _________ 55 dB (WIDE )
Captuer ratio ............ 1.0 dB (WIDE). 2.5 dB (NARROW)
Alternate channel selectivity
(± 400 kHz).............................................. 60 dB (WIDE)
Image rajection ratio (at 98 MHz).............. .............^82 dB
IF rejection ratio (at 98 MHz)................................. 11 0 dB
Spurious rejection ratio (at 98 MHz).....................1 05 dB
AM suppression ratio ........ ................... .. ............ _76 dB
Frequency response
(20 Hz- 15 kHz) .................................. +0.5 dB, -0.5 dB
Output level/lmpedance
(at 1 kHz, 100% dev.).................................. . 0.6V/3.3kO
............... . 9 kHz step
...... .— 10 kHz step
.... 10
(350 jLiV/m)
AM Tuner Section
Tuning frequency range
531 kHz-1,602 kHz.............
530 kHz-1,610 kHz ............
Usable sensitivity ...............
Signal to noise ratio
(at 30% mod. ImV input) ...................................... 52 dB
Total harmonic distortion ............................ ........... 0.3%
Image rejection ratio (Loop).................................... 40 dB
Selectivity............... .................................................. 30 dB
Output level/lmpedance
(at 30% mod.) ........................................ 0.1 8 V/3.3 kO
For Europe type
FM tuner Section
Tuning frequency range ............... 87.5 MHz-108 MHz
Usable sensitivity (DIN)
MONO..,......................................................................... 0.7 fxM
STEREO .................................................................. 25^tV
Limiting level (DIN at 75 O) ................................. 0.45 fiM
Total harmonic distortion (DIN at 1 kHz)
MONO .................................................... 0.07% (WIDE)
STEREO ..................................................... 0.2% (WIDE)
Signal to noise ratio
(DIN weighted at 1 kHz, 65.2 dBf input)
MONO .................................................................... 78 dB
STEREO ................................................................ 67 dB
Stereo separation (DIN)
1 kHz.........................................................52 dB (WIDE )
6.3 kHz.............. ........................................ 42 dB (WIDE)
Captuer ratio..............1.0 dB (WIDE), 2.5 dB (NARROW)
Alternate channel selectivity
(DIN ± 300 kHz) ................................. 75 dB (NARROW)
Image rajection ratio (at 98 MHz)...........................82 dB
IF rejection ratio (at 98 MHz)................................ 11 0 dB
Spurious rejection ratio (at 98 MHz) ................. 1 05 dB
AM suppression ratio ... ........................................... 76 dB
Frequency response
(20 Hz- 15 kHz) ................................ +0.5 dB, -0.5 dB
Output level/lmpedance
(at 1 kHz. 100% dev.).................. ........ ....... 0.6V/3.3kO
531 kHz- 1,602 kHz
... 10 /tV (350 /iV/m)
MW Tuner Section
Tuning frequency range ...
Usable sensitivity..................
Signal to noise ratio
(at 30% mod. ImV input) ....................... ..... ......... 52 dB
Total harmonic distortion .........................................0.3%
Image rejection ratio (Loop).................................... 40 dB
Selectivity.................................................................. 30 dB
Output level/lmpedance
(at 30% mod.) ........................................ 0.1 8 V/3.3 kCl
General
Power consumption
Dimension ........ ..........
Weight .
...................... ........ 1 5 W
,,W: 440 mm (1 7-5/16")
H: 98 mm (3-7/8”)
D; 318 mm (12-1/2")
__ _ 4.3 kg (9.46 lb)
LW Tuner Section
Tuning frequency range ... ................1 53 kHz- 281 kHz
Usabel sensitivity .. ................. ........ . 1 0 /¿V (600 jaV/m)
Signal to noise ratio
(at 30% mod. ImV input) ..................... .................50 dB
Total harmonic distortion .........................................0.4%
Image rejection ratio (Loop).................................... 40 dB
Selectivity .................................................................30 dB
Output level/lmpedance
(at 30% mod.) ........ ................................0.1 8 V/3.3 kil
General
Power consumption
Dimension ..................
Weight (Net) .
............ 15 W
. W; 440 mm
H: 98 mm
D: 318 mm
........... 4.3 kg
Note: ------------------------------------------------ -—-------------------------------------------------------------------------------------------------------------------------------------------------
KENWOOD follows a policy of continuous advancements in development. For this reason specifications may be changed without notice.
