FRONT PANEL CONTROLS AND INDICATORS
® C 6 ) ®
(8)® (n)
T - f f V
1 A
unneR
®C3)
®
(b
(D Channel Selector . . , Selects the
desired channel. LED display shows 0)
through 88. Ad channels are displayed
by two digits, including “0" on the first
digit.
® Microphone Connector . . . Re
ceptacle for microphone connection.
@
ON/OFF
VOLUME
.
.
.
Turns
power on and adjust the listening level.
Whenever the power is turned on, the
unit automatically goes to Channel J6.
® SQUELCH . . . Used to silence the
background noise when no signal is be
ing received. Turn the knob just past
the point where background noise
stops.
® DIM/BRIT Selector . .
the brightness of the display.
Adjusts
@ CHI6 Selector . . . Provides instant
tuning toCH 16 overriding Rotary Chan
nel selector. LED indicator and Channel
display will indicate when unit is on
Channel 16. When you press "OFF", the
channel will go back to the channel
tuned just before you pressed 'CH J6"
The Channel display will go back to that
channel.
TX LED Indicator
the transmit mode.
. Glows red in
® CH16 LED Indicator . . . Lights
when CHI6 SELECTOR is activated.
® 1 WATT LED Indicator . . . Shows
when unit is switched to Low power (I
WATT).
® LED Channei Display
cates channel in use.
Indi-
®
1W/25W
Selector
.
.
.
Controls
transmitter output power. Use the IW
(WATT) position for in-port or short
range communications.
COUTfON: When CH87A is used. LED
channel display shows as
8 7 , 8 (bigger
than 7) and 7 (smaller than
8 } by
comparison.
