2007-08 MAZDA CX-7
DASH DISASSEMBLY AND RADIO REMOVAL INSTRUCTIONS
1. Carefully pull forward and remove the entire trim bezel from around the radio
and Climate controls.
2. Remove the (4) Phillips screws securing the radio to the sub-dash,
disconnect all attached harnesses and antenna lead and remove radio.
Hazard Switch Removal Instructions
f. Disconnect the harness attached to the back of the factory hazard switch.
2. Remove the (2) Phillips screws securing the Hazard switch to the rear
of the factory radio.
3. Remove the (4) Phillips screws securing the chassis of the factory radio
to the rear of the radio face and set aside the chassis.
4. Using a pick tool, or a jewelers flat blade screwdriver, carefully lift upward the back
top and bottom edge locking tabs securing the front portion of the Hazard button to
the rear section of the Hazard switch, and separate the 2 pieces and remove switch
from the face of the factory radio.
Hazard Switch Installation Instructions
1. Place the front Hazard switch into the position on the installation kit and insert the
back section of the Hazard switch from the rear and lock the 2 pieces together.
2. Secure the back of the hazard switch to the rear of the kit using the Phillips screws
removed in step 2 of Hazard switch removal instructions.
NDTES
