Limited Warranty and Connected Equipment Guarantee
TECHNICAL SPECIFICATIONS
Model
PP1500
PP2200
Capacity (VA)
A
V
0
0
2
2
A
V
0
0
5
1
Capacity (Watts)
W
0
0
5
1
W
0
0
0
1
Input
Input Voltage Range
85Vac – 150Vac
Frequency Range
50/60 Hz +/- 3Hz
Output
On Battery Output Voltage
Pure Sine Wave at 120Vac +/- 7%
On Battery Output Frequency
47-53Hz for 50Hz nominal, 57-63Hz for 60Hz nominal
Transfer Time (Typical)
4ms
Overload Protection
On Utility: Circuit Breaker, On Battery: Internal Current Limiting
g
n
ir
e
tl
i
F
d
n
a
n
o
it
c
e
t
o
r
P
e
g
r
u
S
Lightning / Surge Protection
Yes
Internet Ready
(DSL / Phone / FAX / Modem Protection)
RJ11/RJ45 (One In/One Out)
Physical
Total # of UPS Receptacles
(8) NEMA 5-15R
(2) NEMA 5-20R
(6) NEMA 5-15R
Dimensions (cm)
42.0*18.0*23.5
Weight (kg)
25.4
31.1
Battery
Sealed Maintenance Free Lead Acid Battery
4
x
H
A
0
.
9
/
V
2
1
4
x
H
A
0
.
7
/
V
2
1
Hot Swappable Battery
Yes
Typical Recharge Time
8 Hours
Warning Diagnostics
Indicators
Power On, Using Battery, AVR, Wiring Fault, Load Level, Battery Level
Audible Alarms
On Battery, Low Battery, Overload
Environmental
Operating Temperature
+32°F to 95°F ( 0°C to 35°C )
Operating Relative Humidity
0% to 95% Non Condensing
Communication
PowerPanel Business Edition Software
a
M
,
3
0
0
2
r
e
v
r
e
S
,
P
X
/
0
0
0
2
/
T
N
/
E
M
/
8
9
/
5
9
s
w
o
d
n
i
W
c OSX, Linux
Management
Self-Test
Manual Self-Test
Auto-Charger/ Auto-Restart/USB
Yes
SNMP/ HTTP Network Card
Optional
DEFINITIONS FOR ILLUMINATED LED INDICATORS
Power On
AVR
Using
Battery
Circuit
Breaker
Alarm
Condition
l
a
m
r
o
N
f
f
O
t
e
S
f
f
O
f
f
O
n
O
On
Slow flash
Off
Set
Off
AVR- Max. boost 13% of input voltage for output regulation while
input voltage is from 5% to 14% under nominal.
On
Rapid flash
Off
Set
Off
AVR- Max. boost 26% of input voltage for output regulation while
input voltage is from 15% to 29% under nominal.
ON
On
Off
Set
Off
AVR- Max. buck 11% of input voltage for output regulation while
input voltage is from 8% to 25% over nominal.
Off
Off
On
Set
Two Beeps
Utility Failure- The UPS is providing battery power to the
Battery-Power Supplied outlets.
Off
Off
On
Set
Rapid Beeps
Utility Failure- The UPS is providing battery power. Rapid beeps
indicate the battery will run out of charge within a few minutes.
On/Off
On/ Off
/Flash
On/Off
Set
Long Beep
Overload- Turn the UPS off and unplug at least one piece of
equipment from the UPS. Wait 5 seconds, reset the circuit breaker
and restart the UPS.
Off
Off
On
Up
Long Beep
Overload- Turn the UPS off and unplug at least one piece of
equipment from the UPS. Wait 5 seconds, reset the circuit breaker
and restart the UPS.
Off
Off
Off
Set
Off
Surge Protection Malfunction- Power surge has damaged the unit.
Please contact CyberPower Systems.
Read the following terms and conditions carefully before using the CyberPower UPS (the “Product”). By using the Product you consent to be
bound by and become a party to the terms and conditions of this Limited Warranty and Connected Equipment Guarantee (together referred to
as this “Warranty”). If you do not agree to the terms and conditions of this Warranty, you should return the Product for a full refund prior to using
it.
Who Is Providing This Warranty?
CyberPower Systems (USA), Inc. (“CyberPower”) provides this Limited Warranty.
What Does This Warranty Cover?
This warranty covers defects in materials and workmanship in the Product under normal use and conditions. It also covers equipment that was
connected to the Product and damaged because of the failure of the Product.
What Is The Period of Coverage?
This warranty covers the Product for three years and connected equipment for as long as you own the Product.
Who Is Covered?
This warranty only covers the original purchaser. Coverage ends if you sell or otherwise transfer the Product.
How Do You Get Service?
1.
Call us at (877) 297-6937 or write to us at Cyber Power Systems (USA), Inc., 4241 12th Ave. E., STE 400, Shakopee, MN 55379 or
send us an e-mail message at [email protected] for instructions.
2.
When you contact CyberPower, identify the Product, the Purchase Date, and the item(s) of Connected Equipment. Have information
on all applicable insurance or other resources of recovery/payment that are available to the Initial Customer and Request a Claim Number.
3.
You must provide a purchase receipt (or other proof of the original purchase) and provide a description of the defect.
4.
Pack and ship the product to CyberPower and, if requested, the item(s) of Connected Equipment, a repair cost estimate for the
damage to the Connected Equipment, and all claim forms that CyberPower provides to you. Show the Claim Number on the shipping label or
include it with the product. You must prepay all shipping costs, you are responsible for packaging and shipment, and you must pay the cost of
the repair estimate.
How Long Do I Have To Make A Claim?
All claims must be made within ten days of the occurrence.
What Will We Do To Correct Problems?
CyberPower will inspect and examine the Product.
If the Product is defective in material or workmanship, CyberPower will repair or replace it at CyberPower's expense, or, if CyberPower is unable
to or decides not to repair or replace the Product (if defective) within a reasonable time, CyberPower will refund to you the full purchase price
you paid for the Product (purchase receipt showing price paid is required).
If it appears that our Product failed to protect any equipment plugged into it, we will also send you forms for making your claim for the connected
equipment. We will repair or replace the equipment that was damaged because of the failure of our Product or pay you the fair market value
(NOT REPLACEMENT COST) of the equipment at of the time of the damage. We will use Orion Blue Book, or another a third-party valuation
guide, or eBay, craigslist, or other source to establish that amount. Our liability is limited to the Connected Equipment Guarantee amount as
stated in the Technical Specifications section.
Who Pays For Shipping?
We pay when we send items to you; you pay when you send items to us.
What Are Some Things This Warranty Does Not Cover?
1.
This Warranty does not cover any software that was damaged or needs to be replaced due to the failure of the Product or any data that
is lost as a result of the failure or the restoration of data or records, or the reinstallation of software.
2.
This Warranty does not cover or apply to: misuse, modification, operation or storage outside environmental limits of the Product or the
equipment connected to it, nor for damage while in transit or in storage, nor if there has been improper operation or maintenance, or use with
items not designed or intended for use with the Product, such as laser printers, appliances, aquariums, medical or life support devices, etc.
What are the Limitations?
1.
This Warranty does not apply unless the Product and the equipment that was connected to it were connected to properly wired and
grounded outlets (including compliance with electrical and safety codes of the most current electrical code), without the use of any adapters or
other connectors.
2.
The Product must have been plugged directly into the power source and the equipment connected to the Product must be directly
connected to the Product and not “daisy-chained” together in serial fashion with any extension cords, another Product or device similar to the
Product, surge suppressor, or power tap. Any such installation voids the Limited Warranty.
3.
The Product and equipment connected to it must have been used properly in a suitable and proper environment and in conformance
with any license, instruction manual, or warnings provided with the Product and the equipment connected to it.
4.
The Product must have been used at all times within the limitations on the Product’s VA capacity.
Where Can I Get More Information?
For further information please feel free to contact CyberPower at Cyber Power Systems (USA), Inc. 4241 12th Ave E., STE 400, Shakopee, MN
55379; call us at (877) 297-6937; or send us an e-mail message at [email protected].
FCC Notice
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device
may not cause harmful interference, and (2) this device must accept any interference received, including interference
that may cause undesired operation.
WARNING!! This equipment has been tested and found to comply with the limits for a Class B Digital Device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following measures: (1) Reorient or relocate the receiving antenna.
(2) Increase the separation between the equipment and receiver. (3) Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected. (4) Consult the dealer or an experienced radio/TV technician for help. Any special accessories needed for
compliance must be specified in the instruction.
The Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulation.
Cet appareil numerique de la class B respecte toutes les exigencies du Reglement sur le materiel brouilleur du Canada
