CAUTION!
• When installing the Power Distribution Center
cover, it is important to ensure the cover is prop-
erly positioned and fully latched. Failure to do so
may allow water to get into the Power Distribu-
tion Center, and possibly result in a electrical
system failure.
• When replacing a blown fuse, it is important to
use only a fuse having the correct amperage
rating. The use of a fuse with a rating other than
indicated may result in a dangerous electrical
system overload. If a properly rated fuse contin-
ues to blow, it indicates a problem in the circuit
that must be corrected.
Rear Power Distribution Center Fuses
Cavity Fuse Circuits
1 60 Amp
Clear Ignition Off Draw
2 40 Amp
Green Battery
Cavity Fuse Circuits
3 — —
4 40 Amp
Green Battery
5 30 Amp
Pink Heated Seat/Steering Column
6 20 Amp
Yellow Fuel Pump
7 — —
8 15 Amp
Dk. Blue Ignition Start/Run - Start
9 20 Amp
Yellow Console Power Outlet
10 10 Amp
Red Rear Fog Lamp — If Equipped
11 25 Amp
C/BRKR Memory Module/Door Locks
12 25 Amp
C/BRKR Passenger Power Seat
13 30 Amp
C/BRKR Door Module Run/Acc/Delay
MAINTAINING YOUR VEHICLE 319
7
