Cerwin-Vega! CVP-2153 & CVP-1152 Loudspeaker Systems
10. SUSPENSION OF THE CVP SERIES
Remove the fly bracket screws in the fly points where you want to install M10 eye bolts. Screw in the M10 eye
bolts being careful not to strip the fly bracket screw insert point. Do not remove fly bracket screws from areas
where you will not install eye bolts – insure that either an eye bolt or a fly bracket screw is installed in all fly
bracket screw insert locations.
De-rating
Using the mounting points at an angle will de-rate the WLL (Working Load Limit) for each mounting point. Each
point mounted at an angle should be de-rated according to the following formula.
-
WLL = cosine (angle) x 500
-
Where: angle = degrees form vertical pull
500 = WLL for each CVP mounting point @ vertical pull
11. SPECIFICATIONS
Cerwin-Vega! Loudspeaker Systems
CVP-1152
CVP-2153
Frequency Range -10 dB
50 Hz - 20 kHz
37 Hz - 20 kHz
Frequency Response -3 dB
59 Hz - 18.5 kHz
48 Hz - 18.5 kHz
Sensitivity @ 1w / 1 Meter
99 dB
101 dB
Power Capacity RMS / PK
500 / 1000 w
1000 / 2000 w
Recommend Amplifier Power
750 w - 1000 w
1500 w - 2000 w
Maximum SPL
130 dB
134 dB
Coverage Pattern
60 x 40 rotatable
60 x 40 rotatable
HF Diaphragm Size
1.75”
1.75”
Weight
66.5 lbs
112.5 lbs
Fly Points
Yes
Yes
Bi Amp use
Yes
Yes
Rotatable Horn
Yes
Yes
HF Protection
Fast Reacting Suppression Limiter
Woofer
Ceramic 3” VC
Construction
Multi-ply Hardwood
Finish
Polyurethane Paint
