ALARM DASH MOUNTED LED INDICATORS
RAPID FLASHING
= PASSIVE ARMING
SLOW FLASHING = ARMED
OFF = DISARMED
ON SOLID = VALET MODE
2 FLASH...SOLID = REMOTE START VALET MODE
3 FLASH...PAUSE = INTRUSION ZONE 3
2 FLASH...PAUSE = INTRUSION ZONE 2
1 FLASH...PAUSE = INTRUSION ZONE 1
ALARM SIREN/HORN CHIRP INDICATION
1 CHIRP
= ARM
2 CHIRPS = DISARMED
3 CHIRPS = ARMING WITH ENTRY POINT OPENED
4 CHIRPS = DISARM AFTER INTRUSION
5 CONTINUOUS = TRIGGERED/PANIC
ALARM PARKING LIGHT INDICATIONS
1 FLASH
= ARM
2 FLASH = DISARM
3 FLASH = DISARM AFTER INTRUSION
CONTINUOUS FLASH = TRIGGERED/PANIC
REMOTE START SIREN/HORN INDICATIONS
1 LONG/1SHORT
= RF START COMMAND ISSUED
(IF SELECTED ON)
REMOTE START PARKING LIGHT INDICATIONS
1 FLASH
= RF START COMMAND ISSUED
ON = RUNNING UNDER REMOTE START
CONTROL (IF SELECTED)
CONTINUOUS FLASH = RUNNING UNDER REMOTE START
CONTROL (IF SELECTED)
CA 611 SYSTEM FUNCTIONS AT A GLANCE
