No display appears

or abnormal display

a p p e a r s o n t h e

LCD panel.

Buzzer beeps con-

tinuously.

"Distance Scale

Unit" display is

wrong.

T h e p u l s e r a t e

reading is not dis-

played.

The target pulse

rate alarm does not

beep.

Press the advance button

and

check if the display appears or not.

Proceed "All-clear Process", and

press the advance button

and

check if the display appears or not.

[Page 10 (Fig. 4)]

Check if your upper-limit pulse rate

(PLL) has been set correctly. [Page

13-2]

Check if the distance scale unit was

set correctly according to instruc-

tions. [Page 5-7]

Check if the sensor plug is inserted

properly. [Page 7-5]

Check if the pulse sensor is cor-

rectly attached to your earlobe.

[Page 7-6]

Check if the plug or the cable of the

pulse sensor is damaged. [Page 7]

Has your pulse rate once reached

the target pulse rate? [Page 10]

Is the Target Pulse On/Off mark

lit on the screen? [Page 10]

If still no display ap-

pears, the batteries are

dead. Replace all four

batteries. [Page 10 ]

Input your age correctly.

The upper-limit pulse

rate is set at [200 – age].

Follow instructions on

page 6-1 to set the de-

sired distance unit.

Insert the sensor plug

properly, and attach the

pulse sensor correctly.

In case of damage on

the pulse sensor, re-

place it with a new one.

The target pulse rate

alarm is activated only

after your pulse rate

reaches the target.

Press the Target Pulse

O n / O f f b u t t o n

t o

turn on the

mark.

Trouble Shooting / Warranty Service
Specifications

Trouble Shooting

Trouble

Check Item

Suggested Remedy

Warranty Service

• Cat Eye Co., Ltd. guarantees that the Cateye Ergociser™ Model EC-L3200 is free

from material defects and malfunctions under correct and normal use for a period

specified in the separate Warranty Card. In case there should be defects or malfunc-

tions, Cat Eye will repair or replace the unit or parts, according to the terms and

conditions mentioned in the Warranty Card.

• If repair service is required, contact your dealer where the unit was purchased.

• The warranty covers only the main unit and the control unit. Accessories such as the

pulse sensor are not covered.

ITEM

SPECIFICATIONS

Load

Eddy current system utilizing permanent magnet

Load Range

Manual Adjustment

1 ~ 8 level

Cadence

50 ~ 120 rpm

Load Range

25 ~ 680 watts

Acceleration

2-step belt drive

Control System

4-bit micro-computer

Display Function

Function

Range

Accuracy

Pulse Rate

50 ~ 220 bpm

1 bpm (stable state)

Cadence

20 ~ 240 rpm

1 rpm

Exercise Time

00 min. 00 sec. ~ 99 min. 59 sec.

0.003 %

Work Rate

0 ~ 999 watts

5 watts (at 50 watts)

Speed

0 ~ 99 miles/h (km/h)

Simulated value

Distance

0.00 ~ 99.99 miles (km)

Simulated value

Calorie

0 ~ 999 kcal

Estimated value

Alarm Function

Target Pulse Rate Alarm

Signals if the pulse rate deviates from target pulse rate zone

Upper-limit Pulse Rate Alarm

Signals when pulse rate exceeds preset upper-limit pulse rate

Exercise Time Alarm

Signals when preset target exercise time is reached

Power Supply

AA (R6) x 4 (Battery life: Approx. 200 hours by alkaline battery)

User's Weight Limit

286 lbs (130 kg)

Measurement

Handlebar Height:

39-7/32 ~ 52-7/16 inches (996 ~ 1332 mm)

Saddle Height:

33-9/32 ~ 46-31/32 inches (845 ~ 1193 mm)

Length:

42-11/32 inches (1075 mm)

Width:

19-11/16 inches (500 mm)

Weight

Net Weight:

55.5 lbs. approx. (27 kgs)

* Specifications and design are subject to change without notice.

U.S. Pat. 4929825 / Design Pat. Pending
