IMPORTANT
THE SPECIFICATIONS GIVEN IN THIS PUBLICATION DO NOT INCLUDE NORMAL MANUFACTURING
TOLERANCES. THEREFORE, UNITS MAY NOT MATCH THE LISTED SPECIFICATIONS EXACTLY. ALSO,
PRODUCTS ARE TESTED AND CALIBRATED UNDER CLOSELY CONTROLLED CONDITIONS, AND SOME
MINOR DIFFERENCES IN PERFORMANCE CAN BE EXPECTED IF THOSE CONDITIONS ARE CHANGED.
SUPER TRADEUNE MODELS
SUPER TRADELINE controls offer features not
available on TRADELINE or standard models, and
are designed to replace a wide range of Honeywell
and competitive controls.
SUPER TRADELINE MODELS AVAILABLE:
RA117A Stack Mounted Protectorelay
Special SUPER TRADELINE packaging with
cross reference label and SUPER TRADELINE in
struction sheet.
TRADELINE MODELS
TRADELINE controls offer features not available
on standard models and are designed to replace a wide
range of Honeywell and competitive controls.
TRADELINE MODELS:
RA116A Stack Mounted Protectorelay
Special TRADELINE packaging with cross refer
ence label and TRADELINE instruction sheet.
STANDARD MODELS
MODEL
NUMBER
TYPE OF IGNITION
24V
THERMOSTAT
IGNITION
RATING
INPUT
VOLTAGE
RA116A
Intermittent
ignition^
(formerly called
constant ignition)
2- wire
3- wire
series 10
360 VA
120V/60HZ
RA117A
Interrupted ignition^
(formerly called
intermittent ignition)
2- wire
3- wire
series 10
550 VA
120V/60 Hz
RA817A
Interrupted ignition'^
(formerly called
intermittent ignition)
2-wire
550 VA
110V/50 Hz
120V/60 Hz
220V/50 Hz
240V/60 Hz
» Lockout occurs if flame is not re-established during the safety switch timing.
^ Flame or power failure is followed by a one minute (approximate) scavenging period and one attempt to re-establish the
flame. Lockout occurs if flame is not re-established.
